Light Weight 12V 50A Relay NBC9-A-2 Small Volume Environmental Protection

Brand Name : NBC

Model Number : NBC9-A-2

Certification : RoHS

Place of Origin : China

MOQ : 100pcs

Price : negotiable

Payment Terms : T/T, Western Union, MoneyGram

Supply Ability : 500k per month

Delivery Time : 4weeks

Packaging Details : standard or customization

Key words : 12V 50A Relay

Contact Material : AgSnO2, AgNi

Contact Form : 1A、1B

Switching Power Max. : 22500VA

Switching Voltage Max. : 250VAC

Contact Load Capacity（Resistance) : 90A 250VAC, 60A/250VAC

Switching Current Max. : 90A

Weight : Approx.40g

Contact Now

Light Weight 12V 50A Relay NBC9-A-2 Small Volume Environmental Protection

12V 50A Relay Introduce:

The relay is an electrical control device, which can give a specified input quantity and keep it for a long enough time so that the controlled quantity will undergo a predetermined step change in the electrical output circuit. When the input volume drops to a certain level and maintains for a long enough time, it returns to the initial state.

12V 50A Relay Features:

1. Magnetic latching relay, used for the ammeter.
2. Maximum contact switching current: 90 amps.
3. NO/NC can be switched manually.
4. Good shock and vibration resistance.
5. Environmental protection.

12V 50A Relay Technical Rating:

Technical Rating
Insulation Resistance		Min.100MΩ(500VDC)
Dielectric Strength	Between Contacts	2000VAC 50/60Hz Min
	Between Coil&Contact	4000VAC 50/60Hz Min
Shock Resistance		Operation extremes 10G; Damage limits 100G
Vibration Resistance		10Hz～50Hz double amplitude 1.5mm
Pin Type		Quick Terminal
Ambient Temperature		﹣40℃～70℃
Relative Humidity		85% RH, 40℃
Weight		Approx.40g
Package		Dust-proof type
